10 TRANSPORT READY OPTION (TRRO)
Part No 1143151
81 Invacare
3G Storm Series®
Vehicle-Anchored Belts
This wheelchair has an overall rating of “A” with regard to
accommodating the use and fit of vehicle-anchored belts. This rating is
scored as follows:
The test for Lateral Stability Displacement for Point (P) is shown in
FIGURE 3. The average test result for point (P) is:
• Adult - 0.48 inches (12.3 mm).
• Junior - 0.54 inches (13.7 mm)
FIGURE 3 Vehicle-Anchored Belts
Seating System
Ensure that the factory installed seating system is secured to the wheelchair frame before operation. Refer to the seating system owner’s manual.
For this procedure, refer to FIGURE 3.
RATING DESCRIPTION
A Excellent
B Good
C Fair
D Poor
NOTE: Rear view of wheelchair and human surrogate
secured on test platform and tilted to 45 degrees.
Rear View
Test
Platform
Point (P)
45°
WARNING
This wheelchair has been tested for seating in a motor vehicle with the factory installed seating system only.
When feasible, wheelchair occupants should transfer into the vehicle seat and use the OEM (Original Equipment
Manufacturer) vehicle-installed restraint system
