7 TECHNICAL DATA
Invacare
3G Storm Series® 46 Part No 1143151
7 Technical Data
7.1 Specifications
Models
Overall Dimensions

All dimensions are ± .50 inches unless otherwise indicated.
Arrow 3GAR, 3GAR-CG, 3GARBASE
Torque SP 3GTQSPBASE, 3GTQSP, 3GTQ-CG, 3GTQ-MCG, 3GTQ3-MCG
Torque 3 3GTQ3, 3GTQ3V, 3GTQ3-CG, 3GTQ3-MCG
Ranger X 3GRX, 3GRXBASE, 3GRX-CG
ARROW TORQUE SP TORQUE 3 RANGER X
Base Width (Without Joystick): 25 inches
Base Length (Without Front Rigging):
Standard:
Long Frame:
29.5 inches
32.5 inches
Height
Standard:
Minimum:
Maximum
34.25 inches
34.25 inches
44.25 inches
