7 TECHNICAL DATA
Part No 1143151
47 Invacare 3G Storm Series®
Seat
Wheels
ARROW TORQUE SP TORQUE 3 RANGER X
Seat Angle: Adjustable - 0° to 10°
Seat-to-Floor Height
Standard
Low:
Medium:
High:
17.25 inches (0° Seat Tilt), 17.75 inches (5° Seat Tilt)
19.5 inches (0° Seat Tilt), 20 inches (5° Seat Tilt)
20.25 inches (0° Seat Tilt), 21.25 inches (5° Seat Tilt)
ARROW TORQUE SP TORQUE 3 RANGER X
Casters with Precision Sealed Bearings
Semi-Pneumatic
Standard:
Optional:(with shock fork):
Pneumatic or Foam Filled:
Standard:
Optional:
8 x 2.25 inch
6 x 2 inch
8 x 2 inch
9 x 2.75 inch
8 x 1.25 inch
6 x 2 inch
8 x 2 inches
9 x 2.75 inch
8 x 2.25 inch
6 x 2 inch
8 x 2 inch
9 x 2.75 inch
Caster Forks Standard, Shock Fork (optional)
Drive Wheel (Foam Filled or Pneumatic):
Standard:
Optional (Not available with GB Motors):
14 x 3 inch
N/A
14 x 3 inch
14 x 4 inch
Drive Axle Adjustable (Non-recliners Only)
Anti-Tipper: 3 inch wheels
