10 TRANSPORT READY OPTION (TRRO)
Invacare
3G Storm Series® 80 Part No 1143151
FIGURE2 Wheelchair-Anchored Belts
Pin
Pelvic Belt
Male End
Pin
(Used to secure the vehicle-
anchored upper torso belt.)
Pin
DETAIL “A” - PELVIC BELT
Back Angle
Bracket
Large End of Slot
Belt Mounting
Bracket
Small End of Slot
DETAIL “B”
Large End of Slot
Belt Mounting
Bracket
Small End of Slot
DETAIL “C” - JUNIOR SEATS
