11 SETUP/MAINTENANCE
Part No 1143151
97 Invacare 3G Storm Series®
FIGURE1 Removing/Installing Battery Boxes - Group 24 Wheelchairs without Vent Tray
Front of
Base Frame
Battery Retainer
Assembly
Locked
Position
Rear of
Base Frame
Unlocked
Position
Lever
Lever
DETAIL “A” - WHEELCHAIRS WITH TRRO OR TRBKTS
Bolts and Washers
Front Battery
Retainer Bracket
Short Hex
Screws and
Washers
Top Battery
Retainer
Bracket
Lower Battery Retainer Bracket
Long Hex
Screws
Washers
Top Battery
Retainer Bracket
T-Nuts
Wheelchair
Frame
DETAIL “B”
