To Next PageTo Next PageWhat to do if Invacare Medical Equipment bed functions do not operate?
If the Invacare Medical Equipment bed functions aren't working, first, make sure the power cord is securely plugged into a power source. Next, check that the pendant is correctly connected to the junction box under the bed and that the pendant cable isn't tangled or pinched. Also, inspect the fuse/breaker box. If the motors still don’t function, call Invacare.
What to do if Invacare BAR750 power cord is plugged in, but no functions operate?
If the power cord is plugged in but no functions operate on your Invacare Medical Equipment, the handset or control module may be faulty. Contact Invacare to replace them.
What to do if Invacare BAR750 Medical Equipment head/foot section does not stop moving?
If the head or foot section of your Invacare Medical Equipment doesn't stop moving, examine the pendant for depressed or stuck buttons. If a button is stuck, call your dealer for repair.
How to troubleshoot Invacare BAR750 Medical Equipment if one actuator does not work?
To troubleshoot why one actuator isn't working on your Invacare Medical Equipment, interchange the connections on the control module. Plug the problematic actuator into a connection that is working correctly. If the actuator now operates, but the previously working one doesn't, the control module or handset is faulty and needs replacement.
What causes Invacare Medical Equipment actuator to not function properly?
If the actuator on your Invacare Medical Equipment isn't functioning correctly or at all, check the wiring between the control and the actuator, and try reversing the wires. If that doesn't work, the actuator may be defective and need replacement.
Why doesn't the green power light illuminate on my Invacare Medical Equipment?
If the green power light on your Invacare Medical Equipment isn't on, check the electrical power cord for breaks and ensure it is properly plugged into the control module.
What to do if pressing function on Pendant results in motion other than that intended on Invacare Medical Equipment?
If pressing a function on the pendant results in unintended motion on your Invacare Medical Equipment, verify the motor cable connections to the junction box are correct.
Why Invacare Medical Equipment bed does not stay in place?
If your Invacare Medical Equipment bed does not stay in place, make sure the locking casters are locked.
General| Type | Bariatric Bed |
|---|---|
| Weight Capacity | 750 lbs |
| Frame Material | Steel |
| Mattress Included | No |
| Sleep Surface Length | 80 inches |
| Length | 88 inches |
| Wheel Type | 5-inch casters |
| Sleep Surface Width | 42 inches |
| Brakes | Locking brakes |
Defines DANGER, WARNING, and CAUTION signals used in the manual.
Step-by-step guide for physically putting the bed together.
Instructions for operating the bed's height and section adjustments using the pendant.
Lists common electrical issues, their probable causes, and solutions.
Lists common mechanical issues, their probable causes, and solutions.
