Service
4.
LoosenandremovescrewAthatattachesswingarmto
chassisonleftandrightsideofthemobilitydevice.
5.
LoosenandremovelowerboltBonrearshockabsorber
onleftandrightsideofmobilitydevice.
BecarefulnottoloosemetalbushingAinswing
armB.
6.Removeandreplaceswingarm.
7.
Installpartsinreverseorder.
Whenreinstalling,tightenscrewAto15Nm.
4.8.4Replacingsteeringcolumn
CAUTION!
Riskofaccident
Accidentalrollingcanleadtoaccidents.
Securemobilitydeviceagainstrollingaway.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
10mmwrench
13mmwrench
17mmwrench
19mmwrench
32mmwrench
Phillipsscrewdriver
Supportingwoodenblock
1.Removeseat.
2.Removeshroud.
3.Disconnectbatterycable.
4.
Placeasupportingwoodenblockunderthefrontpartof
theframesothatthefrontwheelisnolongertouching
theoor.
1603798-B23
