Invacare Comet Series User Manual

Comet
9.
Disconnectplugsfrompowermodule.
•Disconnectmotorplug.
•Disconnectplugforelectromagneticbrake.
•Disconnectspeedometerplug.
10.
RemovescrewsAonmudguard.
11.RemovemudguardB.
12.
Removescrews(1)ondriveholder(2).
13.Removedriveholder(2).
14.
Removescrews(1)ondisengaginglever(2).
15.Removedisengaginglever(2).
16.Placesupportingwoodenblockunderswingarm.
Replacingdrivemotor
1.
LoosenthreeAllenscrewsA.
2.Liftmotoroutofholderandtakeitoutoftheframes
totheside.
3.Replacemotor .
Replacingdriveunit
1.
LoosenandremovescrewBonswingarm.Forreplacing
swingarm,see4.8.3Replacingswingarm,page22.
2.LoosenandremovelowerboltAonspring.
3.Liftdriveunitoutofholderandtakeitoutoftheframes
totheside.
4.Replacedriveunit.
301603798-B

Invacare Comet Series Specifications

General

Ground Clearance	2.5 inches (6.35 cm)
Turning Radius	49 inches (124.5 cm)
Seat width	17 inches (43.2 cm)
Weight Capacity	300 lbs (136 kg)
Max. user weight	300 lbs (136 kg)
