INVENTOR EVI-12 Service Manual

39
Outdoor Unit
(1) Cooling Only Models
(2) Cooling & Heating Models
Exploded Views and Parts list
CEVO-09 CEVO-12
1 Front Grill 22413017 22413017 1
2 Cabinet 01433044P 01433044P 1
3 Axial Flow Fan Sub-Assy 1033300901 1033300901 1
4 Fan Motor 15013073 15013073 1
5 Motor Support 0170311101 01703111 1
6 Left Side Plate 20053001 20053001 1
7 Top Cover Sub-Assy 0125304001 0125304001 1
8 Electric Box Assy 0260325603 0260325602 1
9 Main Board 30138099 30138100 1
10 Relay 44020382 44020382 1
11 Clapboard 01233088 01233088 1
12 Chassis Sub-assy 0120390901P 0120390901P 1
13 Condenser Assy 01113463 01113501 1
14 Cut-off Valve Assy 07133164 07133602 1
15 Capillary Sub-Assy 03103936 03063056 1
16 Valve Support 01713089 01713089 1
17 Right Side Plate Sub-Assy 0130318001 0130318001 1
18 Handle assy 26233046 26233046 1
19 Thermal baffle 26113005 26113005 1
20 Discharge Tube 03713424 03733025 1
21 Cut-off valve Sub-Assy 07133189 07133189 1
22 Compressor and fittings 00103761 00103761 1
23 Overload Protector 00181067 00181067 0
24 Terminal cap 22243001 22243001 1
Part Code
DescriptionNO. Qty
EVO-09
1 Front Grill 22413017 22413017 1
2 Front Plate 01433044P 01433044P 1
3 Axial Flow Fan Sub-Assy 1033300901 1033300901 1
4 Fan Motor 15013073 15013073 1
5 Motor Support 0170311101 01703111 1
6 Left Side Plate 20053001 20053001 1
7 Top Cover Sub-Assy 0125304001 0125304001 1
8 Electric Box Assy 02603256 0260325601 1
9 Main Board 30138087 30138096 1
10 Relay 44020382 44020382 2
11 Clapboard 01233088 01233088 1
12 Chassis Sub-assy 0120390901P 0120390901P 1
13 Condenser Assy 01113463 01113501 1
14 Cut-off Valve Assy 07133164 07133163 1
15 Capillary Sub-Assy 03103936 03103937 1
16 Valve Support 01713089 01713089 1
17 Right Side Plate Sub-Assy 0130318001 0130318001 1
18 Handle assy 26233046 26233046 1
19 Thermal baffle 26113005 26113005 1
20 Magnet Coil 4300040050 4300040050 1
21 4-way Valve Assy 0312323701 0312327201 1
22 Compressor and fittings 00103761 00103761 1
23 Overload Protector 00181067 00181067 0
24 Terminal cap 22243001 22243001 1
25 Drainage Joint 06123024 06123024 1
No
Part Code
QtyDescription
EVO-12
