INVENTOR L4VI32-09 Service Manual

Technical Information
4
Service Manual
5
Technical Information
Service Manual
Parameter Unit Value
Model L4VI32-12
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity(Min~Max) W 3500(800~3700)
Heating Capacity(Min~Max) W 3670(900~380)
Cooling Power Input(Min~Max) W 1085(220~1400)
Heating Power Input(Min~Max) W 990(220~1500)
Cooling Current Input A 5.0
Heating Current Input A 4.5
Rated Input W 1500
Rated Current A 7.2
Air Flow Volume(SH/H/M//L/SL) m
3
/h 680/590/490/420/-
Dehumidifying Volume L/h 1.4
EER W/W 3.26
COP W/W 3.71
SEER W/W 6.1
SCOP(Average/Warmer/Colder) W/W 4.0/5.1/3.4
Application Area m
2
16-24
Indoor
Unit
Indoor Unit Model L4VI32-12
Fan Type
Fan Diameter Length(DXL) mm Φ98X633.5
Cooling Speed(SH/H/M//L/SL) r/min 1350/1200/1050/850/-
Heating Speed(SH/H/M//L/SL) r/min 1300/1150/1000/900/-
Fan Motor Power Output W 20
Fan Motor RLA A 0.31
Fan Motor Capacitor μF 1.5
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5
mm 2-1.5
Evaporator Coil Length (LXDXW) mm 635X22.8X306.3
Swing Motor Model MP24BA
Swing Motor Power Output W 2
Fuse Current A 3.15
Sound Pressure Level(SH/H/M//L/SL) dB (A) 42/38/34/31/-
Sound Power Level(SH/H/M//L/SL) dB (A) 56/52/48/45/-
Dimension (WXHXD) mm 845X289X209
Dimension of Carton Box (LXWXH) mm 918X278X364
Dimension of Package(LXWXH) mm 921X281X379
Net Weight kg 10.5
Gross Weight kg 12.5
