INVENTOR V7CI-24WiFiR/U7RS-24

32
Indicatorii telecomenzii
Informatiile sunt asate atunci cand telecomanda este pornita.
Asaj Breeze Away (nu este disponibil)
Asaj functie Active Clean
Asaj functie Fresh (nu este disponibil)
Asaj mod Sleep
Asaj functie Follow Me
Asaj functie Wireless
Asaj Low Battery (daca clipeste)
Indicator de transmisie
Se aprinde cand
telecomanda
transmite semnal
catre unitatea interna.
TIMER ON
TIMER OFF
Asaj
Asaj
Asaj functie
Silence
*
*
*
*
*
*
2%-20%
21%-40%
41%-60%
61%-80%
81%-100%
1%
Aseaza vitezele selectate ale
ventilatorului:
Asaj baleiaj orizontal
Nu este disponibil pentru
aceasta unitate.
Asaj mod TURBO
Nu este disponibil pentru
aceasta unitate
MODE
Arata modul curent,
incluzand:
05
Remote Screen Indicators
Note:
All indicators shown in the figure are for the purpose of clear presentation. But during the actual
operation, only the relative function signs are shown on the display window.
Note:
Not all the models can display
the fan speed values between
AU-100%.
[ ]
*
*
*
*
*
*
*
Information are displayed when the remote controller is power up.
Breeze Away display - not available
Transmission Indicator
MODE display
TIMER ON display
FAN SPEED display
TIMER OFF display
Silence feature
display
ECO display
GEAR display
LOCK display
Horizontal louver
swing display
TURBO mode display
Not available for
this unit
Not available for
this unit
Temperature/Timer/Fan speed
display
Active clean feature display
Fresh feature display - not available
Sleep mode display
Follow me feature display
Wireless control feature display
Low battery detection display(flashing)
Displays when LOCK feature
is activated.
Silence
LOW
MED
HIGH
AUTO
Lights up when remote
sends signal to indoor
unit
Displays selected fan speed:
Displays the current
including:
mode,
2%-20%
21%-40%
41%-60%
61%-80%
81%-100%
1%
This fan speed can not be
adjusted in AUTO or DRY
mode.
Displays when ECO
feature is activated
Displays when GEAR
feature is activated
Displays the set temperature
by default, or fan speed or
timer setting when using
TIMER ON/OFF functions.
Temperature range:
o
o
o
o
16-30 C / /60-86 F
Timer setting range:
0-24 hours
Fan speed setting range:
AU -100%
This display is blank when
operating in FAN mode.
(20-28 C/68-82 F)
(Model dependent)
ECO display
Este afisat atunci cand
functia ECO este activata.
GEAR (nu este disponibil)
Este afisat atunci cand functia
GEAR este activata.
LOCK
Este afisat atunci cand
functia LOCK este activata.
Temperature/Timer/Fan
Afiseaza temperatura
selectata, sau viteza
ventilatorului ori setarea
temporizatorului atunci
cand folositi functiile TIMER
ON/OFF.
• Interval de temperatura:
16-30 °C/60-86 °F/ (20-28
°C/68-82 °F)
• (in functie de model)
• Interval setare
temporizator: 0-24 ore
• Interval setare viteza
ventilator:
• AU - 100%
Afisajul nu arata nimic
atunci cand unitatea
functioneaza in modul
FAN.
Aceasta viteza a ventilatorului nu
poate  ajustata in modurile AUTO
sau DRY.
Nota:[*]
Nu toate modelele pot asa valorile
vitezei ventilatorului intre AU-100%.
Nota:
Toti indicatorii prezentati in imaginea alaturata au scop orientativ. In timpul functionarii, doar
semnele functiilor corespunzatoare vor  asate pe ecranul telecomenzii.
(Ein)
(Aus)
Stille
NIEDRIG
MITTEL
HOCH
AUTOMA-
TISCH
06
Vane
Vane
How to Use Basic Functions
ATTENTION! Before operation, please
ensure the unit is plugged in and power
is available.
AUTO Mode
SETTING TEMPERATURE
The operating temperature range for units
is 16-30°C (60-86°F)/20-28 C(68-82 F).
You can increase or decrease the set
temperature in 1°C (1°F) increments.
In AUTO mode, the unit will automatically select
the COOL, FAN, or HEAT operation based on
the set temperature.
1. Press the MODE button to select AUTO.
2. Set your desired temperature using the TEMP
or TEMP button.
Set your desired temperature using the
TEMP or TEMP button.
3.
Press the ON/OFF button to start the unit.
Press the ON/OFF button to start the unit.
NOTE: FAN SPEED can’t be set in AUTO mode.
COOL Mode
Basic operation
1. Press the MODE button to select COOL
mode.
2.
3.
Press FAN button to select the fan speed
in a range of AU-100%.
4.
1
3
2
1
3
2
4
Asaj vinteza ventilator
