3
192,following the universal DMX 512 protocol，can control 12 16-channel scanners or other
equipment,chase program and manual control of scanners can be performed at the same time .the
functions are compact it’s convenient and flexible operation made it handled very easily.192 is
suitable for different ballroom ,taproom and small show.
Technical specifications
Output signal DMX512
DMX channels 1-192
Maximum control channel amount a scanner 16
Control amount of scanners 12
Amount of chase 12
Maximum chase steos in a chase 100
Amount of scanner scene 100
Running scene directly 12
Manual operation of scanner Yes
Music run Yes
Blackout function Yes
Time of running chase can be adjust Yes
Cross of running chase can be adjust Yes
Display mond LED digit display
Port of DMX outpput XLR-D3F
Power supply AC90-240V,50-60Hz,4W
Size 53.5*18.5*10CM
Weight 2.5KG
Cautions of safety
◆ 192Ccontroller must be connected to the earthground to ensure the safety of user。
◆ When 192 controller are working，don’t plug in or plug out DMX 512 cable to avoid
destroying the electronic components of the port in the controller.
◆ Don’t splash any liquid to the controller to avoid destroying the electric components and the
functions of the controller
◆ The scanner controller is precision electric equipment .please pay attention to moistureproof
protection and dustproof .And please clean the controller panel termly.
Installation of controller
Contents in the package of 192Cscanner controller：
◆ 192Cscanner controller: 1；
◆ Power supply line :1；
◆ User manual : 1。
Installing structure of 192 scanner controller follows the international standard “19”3U.it can be
