INVT CHE100-1R5G-4 - Page 100

List of Function Parameters
93
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
P6.02 AO selection
0: Running frequency
1: Reference frequency
2: Motor speed
3: Output current
4: Output voltage
5: Output power
6: Output torque
7: AI1 voltage
8: AI2 voltage/current
9~10: reserved
0 O 72
P6.03
AO lower limit 0.0%~100.0%
0.0% O 73
P6.04
AO lower limit
corresponding output
0.00V ~10.00V
0.00V O 74
P6.05
AO upper limit 0.0%~100.0%
100.0% O 75
P6.06
AO upper limit
corresponding output
0.00V ~10.00V
10.00V O 76
P7 Group: Display Interface
P7.00 User password 0~65535 0 O 77
P7.01
LCD language
selection
0: Chinese
1: English
0 O 78
P7.02
Parameter copy
0: Invalid
1: Upload from inverter
2: Download to inverter
0

79
P7.03
QUICK/JOG function
selection
0: Jog
1: FDW/REV switching
2: Clear UP/DOWN setting
0

80
P7.04
STOP/RST function
option
0: Valid when keypad control (P0.01=0)
1: Valid when keypad or terminal control
(P0.01=0 or 1)
2: Valid when keypad or communication
control (P0.01=0 or 2)
3: Always valid
0 O 81
P7.05
Keypad display
selection
0: Preferential to external keypad
1: Both display, only external key valid.
2: Both display, only local key valid.
3: Both display and key valid.
0 O 82
