CHE Series Sensorless Vector
Control Inverter
Operation Manual
z Thank you very much for your buying CHE series sensorless vector control
inverter.
z
Before use, please read this manual thoroughly to ensure proper usage. Keep this
manual at an easily accessible place so that can refer anytime as necessary.

Table of Contents

Questions and Answers

  • H
    hoganmaryAug 20, 2025
    What to do if there is over-current during acceleration in INVT DC Drives?
    • J
      josephscottAug 20, 2025
      If the INVT DC Drive displays an over-current error during acceleration, it could be due to several reasons. There might be a short-circuit or ground fault at the inverter output, the load could be too heavy, the acceleration/deceleration time might be too short, the V/F curve might be unsuitable, or there could be a sudden change in load. To resolve this: * Inspect the motor for damage, worn insulation, or cable damage. * Increase the acceleration/deceleration time or select an inverter with a larger capacity. * Check and adjust the V/F curve, and also check the load.
  • T
    Terry CooperAug 22, 2025
    Why is my INVT DC Drives showing inverter overload?
    • P
      Patrick VaughnAug 22, 2025
      If your INVT DC Drive displays an inverter overload, it could be due to a heavy load, short acceleration/deceleration time, an unsuitable V/F curve, or the inverter's capacity being too small. Here's how to address it: * Increase the acceleration/deceleration time or choose an inverter with a larger capacity. * Check and adjust the V/F curve. * Consider selecting an inverter with a higher capacity.
  • M
    Mckenzie JonesAug 25, 2025
    How to fix IGBT Ph-U fault in INVT CHE100-1R5G-4 DC Drives?
    • C
      cevansAug 25, 2025
      If the INVT DC Drive shows an IGBT Ph-U fault, it could be due to several reasons: the acceleration/deceleration time being too short, a fault in the IGBT module itself, malfunction caused by interference, or improper grounding. To address this: * Increase the acceleration/deceleration time. * Inspect external equipment and eliminate any interference.
  • A
    ahamiltonAug 26, 2025
    What causes over-voltage during acceleration in INVT DC Drives?
    • B
      brownryanAug 26, 2025
      If the INVT DC Drive shows an over-voltage error during acceleration, it could be due to a short deceleration time causing excessive regenerative energy from the motor, or the input voltage being too high. To fix this, you can: * Increase the deceleration time or connect a braking resistor. * Decrease the input voltage to stay within the specified range.
  • X
    xsimsAug 27, 2025
    Why is my INVT CHE100-1R5G-4 DC Drives showing motor overload?
    • S
      Stephen PetersonAug 27, 2025
      If the INVT DC Drive indicates a motor overload, it may be because the motor is driving a heavy load at low speed for an extended period, the V/F curve is not properly set, the motor’s overload protection threshold (PB.01) is incorrect, or there is a sudden load change. To resolve this: * Select a variable frequency motor. * Check and adjust the V/F curve. * Check and adjust PB.01. * Check the load.
  • E
    Emily HebertAug 29, 2025
    What causes DC bus Under-voltage in INVT CHE100-1R5G-4?
    • J
      Javier GordonAug 29, 2025
      If the INVT DC Drive displays a DC bus under-voltage error, it could be due to an open phase in the power supply, a momentary power loss, loose wiring terminals for the input power supply, or large voltage fluctuations in the power supply. Inspect the input power supply or wiring.
  • T
    Tammy WalshAug 31, 2025
    What to do if INVT CHE100-1R5G-4 DC Drives shows input phase failure?
    • C
      Chase BryanAug 31, 2025
      If the INVT DC Drive shows an input phase failure, it could be due to an open phase in the power supply, a momentary power loss, loose wiring terminals for the input power supply, large voltage fluctuations in the power supply, or poor voltage balance between phases. Check the wiring, installation, and power supply.
  • R
    Robin AndersonSep 2, 2025
    How to resolve rectify overheat in INVT CHE100-1R5G-4 DC Drives?
    • J
      Jeffrey WhiteheadSep 2, 2025
      If the INVT DC Drive displays a rectify overheat error, it could be due to high ambient temperature, proximity to a heat source, cooling fan issues (stopped or damaged), obstructed ventilation, or a high carrier frequency. To solve this: 1. Install a cooling unit. 2. Remove any nearby heat sources. 3. Replace the cooling fan. 4. Clear any obstructions in the ventilation channel. 5. Decrease the carrier frequency.
  • M
    Megan SmithSep 4, 2025
    What causes output phase failure in INVT CHE100-1R5G-4 DC Drives?
    • E
      ellisnicoleSep 4, 2025
      If the INVT DC Drive indicates an output phase failure, it could be due to a broken wire in the output cable, a broken wire in the motor winding, or loose output terminals. Check the wiring and installation.
  • K
    Kylie MorrisonSep 6, 2025
    How to troubleshoot communication fault in INVT CHE100-1R5G-4 DC Drives?
    • P
      Patricia PerezSep 6, 2025
      If the INVT DC Drive displays a communication fault, it may be due to an incorrect baud rate setting, receiving incorrect data, or a prolonged interruption in communication. To solve this, set the proper baud rate and check the communication devices and signals.

Summary

Introduction

1.1 Technology Features

Key technical specifications and capabilities including input/output, I/O features, and main control functions.

Wiring

4.2 Terminal Configuration

Details the layout and function of the main and control circuit terminals on the inverter.

4.3 Typical Wiring Diagram

Presents a comprehensive wiring diagram showing inverter connections to power, motor, and other components.

4.5 Main Circuit Wiring

Detailed Function Description

6.1 P0 Group-Basic Function

Covers fundamental settings like control mode selection, run command source, and frequency settings.

6.2 P1 Group-Start and Stop Control

6.3 P2 Group-Motor Parameters

Explains the input and configuration of motor nameplate parameters essential for optimal inverter performance.

6.4 P3 Group-Vector Control

Describes parameters for vector control, including ASR proportional gain and integral time settings.

6.5 P4 Group- V;F Control

6.12 PB Group- Protection Function

Covers motor overload protection, over-voltage stall, and current limiting functions for safety.

6.13 PC Group-Serial Communication

Trouble Shooting

7.1 Fault and Trouble shooting

Lists common fault codes, their reasons, and corresponding solutions for diagnosing inverter issues.

7.2 Common Faults and Solutions

Provides solutions for frequently encountered operational faults and malfunctions like no display or power supply issues.

List of Function Parameters

P0 Group: Basic Function

P2 Group: Motor Parameters

Lists parameters for configuring motor properties, essential for autotuning and performance.

P3 Group: Vector Control

Lists parameters specific to vector control mode, including PID gains and switching points.

P9 Group: PID Control

PB Group: Protection Function

INVT CHE100-1R5G-4 Specifications

General IconGeneral
Power1.5 kW
Output Voltage0-380V AC
Protection LevelIP20
Input Voltage380V AC
Control ModeV/F control
Protection FeaturesOvercurrent, Overvoltage, Undervoltage, Overload, Overtemperature, Short circuit
