List of Function Parameters
90
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
P2.02
Motor rated
frequency
0.01Hz~P0.04
50.00Hz

30
P2.03
Motor rated speed 0~36000rpm
Depend
on model

31
P2.04
Motor rated voltage 0~2000V
Depend
on model

32
P2.05
Motor rated current 0.8~2000.0A
Depend
on model

33
P2.06
Motor stator
resistance
0.001~65.535Ω
Depend
on model
O 34
P2.07
Motor rotor
resistance
0.001~65.535Ω
Depend
on model
l
O 35
P2.08
Motor leakage
inductance
0.1~6553.5mH
Depend
on model
O 36
P2.09
Motor mutual
inductance
0.1~6553.5mH
Depend
on model
O 37
P2.10
Current without load 0.01~655.35A
Depend
on model
O 38
P3 Group: Vector Control
P3.00
ASR proportional
gain K
p
1
0~100 20 ○
39
P3.01
ASR integral time K
i
1 0.01~10.00s 0.50s ○
40
P3.02
ASR switching point
1
0.00Hz~P3.05 5.00Hz ○
41
P3.03
ASR proportional
gain K
p
2
0~100 15 ○
42
P3.04
ASR integral time K
i
2 0.01~10.00s 1.00s ○
43
P3.05
ASR switching point
2
P3.02~P0.04 10.00Hz ○
44
P3.06
Slip compensation
rate of VC
50.0~200.0%
100% O 45
P3.07
Torque limit 0.0~200.0%
150.0% O 46
