List of Function Parameters
91
Function
Code
Name Description
Factory
Setting
Modify
Serial
No.
P4 Group: V/F Control
P4.00
V/F curve selection
0:Linear curve
1: Torque_stepdown curve (2.0 order)
0

47
P4.01
Torque boost
0.0%: (auto)
0.1％~10.0％
0.0% O 48
P4.02
Torque boost cut-off 0.0%~50.0% (motor rated frequency)
20.0%

49
P4.03
V/F Slip
compensation limit
0.00~200.0%
0.0% O 50
P4.04
Auto energy saving
selection
0: Disabled
1: Enabled
0

51
P4.05 Reserved ● 52
P5 Group: Input Terminals
P5.00 S1 terminal function 1

53
P5.01 S2 terminal function 4

54
P5.02 S3 terminal function 7

55
P5.03 S4 terminal function
0: Invalid
1: Forward
2: Reverse
3: 3-wire control
4: JOG forward
5: JOG reverse
6: Coast to stop
7: Reset fault
8: External fault input
9: UP command
10: DOWN command
11: Clear UP/DOWN
12: Multi-step speed reference 1
13: Multi-step speed reference 2
14: Multi-step speed reference 3
15: ACC/DEC time selection
16: Pause PID
17: Pause traverse operation
18: Reset traverse operation
19: ACC/DEC ramp hold
20: Disable torque control
21: UP/DOWN invalid temporarily
22-25: reserved
0

56
P5.04
ON/OFF filter times
1~10
5 O 57
