INVT CHE100-1R5G-4 - Page 27

Wiring
20
3AC 380V ±15%
CHE100-0R7G-4 10 2.5 10
CHE100-1R5G-4 16 2.5 10
CHE100-2R2G-4 16 2.5 10
CHE100-004G/5R5P-4 25 4 16
CHE100-5R5G/7R5P-4 25 4 16
CHE100-7R5G/011P-4 40 6 25
CHE100-011G/015P-4 63 6 32
CHE100-015G/018P-4 63 6 50
CHE100-018G/022P-4 100 10 63
CHE100-022G/030P-4 100 16 80
CHE100-030G/037P-4 125 25 95
CHE100-037G/045P-4 160 25 120
CHE100-045G/055P-4 200 35 135
CHE100-055G/075P-4 200 35 170
CHE100-075G/090P-4 250 70 230
CHE100-090G/110P-4 315 70 280
CHE100-110G/132P-4 400 95 315
CHE100-132G/160P-4 400 150 380
CHE100-160G/185P-4 630 185 450
CHE100-185G/200P-4 630 185 500
CHE100-220G/250P-4 800 150x2 630
CHE100-250G/280P-4 800 150x2 700
CHE100-280G/315P-4 1000 185x2 780
CHE100-315G/350P-4 1200 240x2 900
