INVT CHE100-2R2G-S2 User Manual

Detailed Function Description
62
0 0 0 1 0 0 0 0
The value of P7.06 is 100Fh.
Notice: I/O terminal status is displayed in decimal.
For details, please refer to description of P7.18 and P7.19.
Function
Code
Name Description
Setting
Range
Factory
Setting
P7.07
Stop status display
selection
0~0x1FF 0~0x1FF 0xFF
P7.07 determines the display parameters in stop status. The setting method is similar
with P7.06.
The display content corresponding to each bit of P7.07 is described in the following table:
BIT7 BIT6 BIT5 BIT4 BIT3 BIT2 BIT1 BIT0
AI2 AI1
PID
feedback
PID
preset
Output
terminal
status
Input
terminal
status
DC bus
voltage
Reference
frequency
BIT15 BIT14 BIT13 BIT12 BIT11 BIT10 BIT9 BIT8
Reserved Reserved Reserved Reserved Reserved Reserved Reserved
Step No. of
multi-step
Function
Code
Name Description
Setting
Range
Factory
Setting
P7.08
Rectifier module
temperature
0~100.0℃
P7.09
IGBT module
temperature
0~100.0℃
P7.10 Software version
P7.11
Accumulated running
time
0~65535h
Rectify module temperature: Indicates the temperature of rectify module. Overheat
protection point of different inverter may be different.
IGBT module temperature: Indicates the temperature of IGBT module. Overheat
protection point of different inverter may be different.
Software version: Indicates current software version of DSP.
