Goodrive10 Series Mini VFD Function parameters
-40-
Function
code
Name
Description
Default
Modify
Setting range of P04.07: P04.05P02.02
(rated frequency of motor)
Setting range of P04.08: 0.0%110.0% (rated
voltage of the motor)
P04.09
Motor V/F
slip
compensa
tion gain
This function code is used to compensate the
change of the rotation speed caused by load
during compensation SVPWM control to
improve the rigidity of the motor. It can be set
to the rated slip frequency of the motor which
is counted as below:
f=f
b
-n*p/60
Of which, f
b
is the rated frequency of the motor,
its function code is P02.02; n is the rated
rotating speed of the motor and its function
code is P02.03; p is the pole pair of the motor.
100.0% corresponds to the rated slip
frequency f.
Note: No torque compensation for 1PH 220V
VFDs.
Setting range:0.0200.0%
380V:
100.0%
220V:0%
P04.10
Low
frequency
vibration
control
factor
In the SVPWM control mode, current
fluctuation may occur to the motor on some
frequency, especially the motor with big
power. The motor can not run stably or
overcurrent may occur. These phenomena can
be canceled by adjusting this parameter.
Setting range of P04.10: 0100
Setting range of P04.11: 0100
Setting range of P04.12: 0.00HzP00.03 (max.
output frequency)
10
P04.11
High
frequency
vibration
control
factor
10
P04.12
Vibration
control
threshold
30.00 Hz
