INVT GD10-2R2G-4-B User Manual

Goodrive10 Series Mini VFD Function parameters
-74-
P17 group Status viewing
Function
code
Name
Description
Default
Modify
P17.00
Set
frequency
Display current set frequency of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.01
Output
frequency
Display current output frequency of the VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of the
VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.03
Output
voltage
Display current output voltage of the VFD.
Range: 0–1200V
0V
●
P17.04
Output
current
Display current output current of the VFD.
Range: 0.0–5000.0A
0.0A
●
P17.05
Motor
speed
Displays current motor speed.
Range: 0–65535RPM
0 RPM
●
P17.08
Motor
power
Displays current motor power; 100% relative to
rated motor power, positive value is motoring
state, negative value is generating state.
Setting range: -300.0%–300.0% (relative to
rated motor power)
0.0%
●
P17.09
Output
torque
Displays current output torque of the VFD; 100%
relative to rated motor torque, positive value is
motoring state, negative value is generating
state.
Range: -250.0–250.0%
0.0%
●
P17.11
DC bus
voltage
Display current DC bus voltage of the VFD
Range: 0.0–2000.0V
0V
●
P17.12
Digital
input
terminal
state
Display current digital input terminals state of the
VFD
Range: 0000–00FF
0
●
P17.13
Digital
output
terminal
state
Display current digital output terminals state of
the VFD
Range: 0000–000F
0
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of
the VFD.
Range : 0.00Hz–P00.03
0.00V
●
