Page #32 background imageLoading...
Page #32 background image
Goodrive20 inverters Function Parameters
31
Function
code
Name Detailed instruction of parameters
Default
value
Modify
source, preset value and feedback source of PID.
8:MODBUS communication setting
The frequency is set by MODBUS communication. See P14
for detailed information.
9~11: Reserved
P00.08
B frequency
command
reference
selection
0:Maximum output frequency, 100% of B frequency setting
corresponds to the maximum output frequency
1: A frequency command, 100% of B frequency setting
corresponds to the maximum output frequency. Select this
setting if it needs to adjust on the base of A frequency
command.
0
P00.09
Combination of
the setting
source
0: A, the current frequency setting is A frequency command
1: B, the current frequency setting is B frequency command
2: A+B, the current frequency setting is A frequency
command + B frequency command
3: A-B, the current frequency setting is A frequency
command - B frequency command
4: Max (A, B): The bigger one between A frequency
command and B frequency is the set frequency.
5: Min (A, B): The lower one between A frequency command
and B frequency is the set frequency.
Note:The combination manner can be shifted by P05
(terminal function)
0
P00.10
Keypad set
frequency
When A and B frequency commands are selected as
“keypad setting”, this parameter will be the initial value of
inverter reference frequency
Setting range:0.00 Hz~P00.03 (the Max. frequency)
50.00Hz
P00.11
ACC time 1
ACC time means the time needed if the inverter speeds up
from 0Hz to the Max. One (P00.03).
DEC time means the time needed if the inverter speeds
down from the Max. Output frequency to 0Hz (P00.03).
Goodrive20 series inverters have four groups of ACC/DEC
time which can be selected by P05. The factory default
ACC/DEC time of the inverter is the first group.
Setting range of P00.11 and P00.12:0.0~3600.0s
Depend
on model
P00.12
DEC time 1
Depend
on model
P00.13
Running
direction
selection
0: Runs at the default direction, the inverter runs in the
forward direction. FWD/REV indicator is off.
1: Runs at the opposite direction, the inverter runs in the
reverse direction. FWD/REV indicator is on.
Modify the function code to shift the rotation direction of the
0
