Note: when analog AI2 select 0~20mA input, the
corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds to the
maximum frequency (function code P00.03) in forward
direction and -100.0% corresponds to the maximum
frequency in reverse direction (function code P00.03)
4:High-speed pulse HDI setting
The frequency is set by high-speed pulse terminals.
Goodrive20 series inverters provide 1 high speed pulse
input as the standard configuration. The pulse frequency
range is 0.00~50.00kHz.
100.0% of the high speed pulse input setting corresponds to
the maximum frequency in forward direction (function code
P00.03) and -100.0% corresponds to the maximum
frequency in reverse direction (function code P00.03).
Note: The pulse setting can only be input by multi-function
terminals HDI. Set P05.00 (HDI input selection) to high
speed pulse input, and set P05.49 (HDI high speed pulse
input function selection) to frequency setting input.
5:Simple PLC program setting
The inverter runs at simple PLC program mode when
P00.06=5 or P00.07=5. Set P10 (simple PLC and multi-step
speed control) to select the running frequency running
direction, ACC/DEC time and the keeping time of
corresponding stage. See the function description of P10 for
detailed information.
6: Multi-step speed running setting
The inverter runs at multi-step speed mode when P00.06=6
or P00.07=6. Set P05 to select the current running step, and
set P10 to select the current running frequency.
The multi-step speed has the priority when P00.06 or
P00.07 does not equal to 6, but the setting stage can only
be the 1~15 stage. The setting stage is 1~15 if P00.06 or
P00.07 equals to 6.
7: PID control setting
The running mode of the inverter is process PID control
when P00.06=7 or P00.07=7. It is necessary to set P09.
The running frequency of the inverter is the value after PID
effect. See P09 for the detailed information of the preset
