Goodrive20 inverters Function Parameters
59
Function
code
Name Detailed instruction of parameters
Default
value
Modify
Displayed
parameters 2
of running state
0x0000~0xFFFF
BIT0: analog AI1 value (V on)
BIT1: analog AI2 value (V on)
BIT2: analog AI3 value (V on)
BIT3: high speed pulse HDI frequency
BIT4: motor overload percentage (% on)
BIT5: the inverter overload percentage (% on)
BIT6: ramp frequency given value(Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9~15:reserved
0x0000
stop state
0x0000~0xFFFF
BIT0:set frequency(Hz on, frequency flickering slowly)
BIT1:bus voltage (V on)
BIT2:input terminals state
BIT3:output terminals state
BIT4:PID reference (% flickering)
BIT5:PID feedback value(% flickering)
BIT6:torque reference(% flickering)
BIT7:analog AI1 value(V on)
BIT8:analog AI2 value(V on)
BIT9: analog AI3 value(V on)
BIT10:high speed pulse HDI frequency
BIT11:PLC and the current step of multi-step speed
BIT12:pulse counters
BIT13~BIT15:reserved
0x00FF
Frequency
display
coefficient
0.01~10.00
Displayed frequency=running frequency* P07.08
1.00
○
Speed display
coefficient
0.1~999.9%
Mechanical rotation speed =120*displayed running
frequency×P07.09/motor pole pairs
100.0%
Linear speed
displayed
coefficient
0.1~999.9%
Linear speed= Mechanical rotation speed×P07.10
1.0%
○
Convertering
module
-20.0~120.0°C
●
