INVT GD20-0R4G-S2 User Manual

Goodrive20 inverters Function Parameters
85
Function
code
Name Detailed instruction of parameters
Default
value
Modify
terminals state
Range: 0000~00FF
P17.13
Switch output
terminals state
Display current Switch output terminals state of the inverter
Range: 0000~000F
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the inverter.
Range : 0.00Hz~P00.03
●
P17.15
Torque
reference
Display the torque reference, the percentage to the current
rated torque of the motor.
Setting range: -300.0%~300.0%
(the rated current of the motor)
●
P17.16
Linear speed
Display the current linear speed of the inverter.
Range: 0~65535
●
P17.17
Reserved ●
P17.18
Counting value
Display the current counting number of the inverter.
Range: 0~65535
●
P17.19
AI1 input
voltage
Display analog AI1 input signal
Range: 0.00~10.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00~10.00V
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00~10.00V
●
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.00~50.00kHz
●
P17.23
PID reference
value
Display PID reference value
Range: -100.0~100.0%
●
P17.24
PID feedback
value
Display PID feedback value
Range: -100.0~100.0%
●
P17.25
Power factor of
the motor
Display the current power factor of the motor.
Range: -1.00~1.00
●
P17.26
Current
running time
Display the current running time of the inverter.
Range:0~65535min
●
