INVT GD20-0R4G-S2 User Manual

Goodrive20 inverters Function Parameters
86
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P17.27
Simple PLC
and the current
stage of the
multi-step
speed
Display simple PLC and the current stage of the multi-step
speed
Range: 0~15
●
P17.28
ASR controller
output
The percentage of the rated torque of the relative motor,
display ASR controller output
Range: -300.0%~300.0% (the rated motor current )
●
P17.29
Reserved ●
P17.30
Reserved ●
P17.31
Reserved ●
P17.32
Magnetic flux
linkage
Display the magnetic flux linkage of the motor.
Range: 0.0%~200.0%
●
P17.33
Exciting current
reference
Display the exciting current reference in the vector control
mode.
Range: -3000.0~3000.0A
●
P17.34
Torque current
reference
Display the torque current reference in the vector control
mode.
Range: -3000.0~3000.0A
●
P17.35
AC input
current
Display the input current in AC side.
Range: 0.0~5000.0A
●
P17.36
Output torque
Display the output torque. Positive value is in the
electromotion state, and negative value is in the power
generating state.
Range : -3000.0Nm~3000.0Nm
●
P17.37
Motor overload
counting
0~100 (OL1 when 100) ●
P17.38
PID output
Display PID output
-100.00~100.00%
●
P17.39
Reserved ●
