INVT GD20-0R7G-4-EU User Manual

Goodrive20-EU series VFD Communication protocol
131
Function instruction
Address
definition
Data meaning instruction
R/W
attribute
Setting frequency
3001H
Range: 0.00Hz – P00.03
R
Bus voltage
3002H
Range: 0 – 2000V
R
Output voltage
3003H
Range: 0 – 1200V
R
Output current
3004H
Range: 0.0 – 3000.0A
R
Operation speed
3005H
Range: 0 – 65535RPM
R
Output power
3006H
Range: -300.0 – 300.0%
R
Output torque
3007H
Range: -250.0 – 250.0%
R
Close loop setting
3008H
Range: -100.0% – 100.0%
R
Close loop feedback
3009H
Range: -100.0% – 100.0%
R
PID setting
3008H
-100.0 – 100.0% (unit: 0.1%)
R
PID feedback
3009H
-100.0 – 100.0% (unit: 0.1%)
R
Input IO
300AH
000 – 1FF
Input IO
300BH
000 – 1FF
AI 1
300CH
Range: 0.00 – 10.00V
R
AI 2
300DH
Range: 0.00 – 10.00V
R
AI 3
300EH
Range: 0.00 – 10.00V
R
AI 4
300FH
Range: -10.00 – 10.00V
R
Read high speed pulse
1 input
3010H
Range: 0.00 – 50.00kHz
R
Read high speed pulse
2 input
3011H
Reserved
R
Read current step
number of multi-step
speed
3012H
Range: 0 – 15
R
External length
3013H
Range: 0 – 65535
R
External counting
value
3014H
Range: 0 – 65535
R
Torque setting
3015H
-300.0 – 300.0% (Unit: 0.1% )
R
VFD code
3016H
R
Fault code
5000H
R
R/W characteristics means the function is with read and write characteristics. For example,
"communication control command" is writing chrematistics and control the VFD with writing
command (06H). R characteristic can only read other than write and W characteristic can only
write other than read.
Note: When operating on the VFD with the table above, it is necessary to enable some
parameters. For example, the operation of running and stopping, it is necessary to set P00.01
