INVT GD20-2R2G-S2 User Manual

Goodrive20 inverters Function Parameters
40
Function
code
Name Detailed instruction of parameters
Default
value
Modify
coefficient 1 for
the iron core of
AM1
P02.12
Magnetic
saturation
coefficient
2 for
the iron core of
AM1
0.0~100.0% 68.0% ◎
P02.13
Magnetic
saturation
coefficient 3 for
the iron core of
AM1
0.0~100.0% 57.0% ◎
P02.14
Magnetic
saturation
coefficient 4 for
the iron core of
AM1
0.0~100.0% 40.0% ◎
P02.26
Motor
overload
protection
selection
0: No protection
1: Common motor (with low speed compensation). Because
the heat-releasing effect of the common motors will be
weakened, the corresponding electric heat protection will be
adjusted properly. The low speed compensation
characteristic mentioned here means reducing the threshold
of the overload protection of the motor whose running
frequency is below 30Hz.
2: Frequency conversion motor (without low speed
compensation). Because the heat-releasing of the specific
motors won’t be impacted by the rotation speed, it is not
necessary to adjust the protection value during low-speed
running.
2 ◎
P02.27
Motor overload
protection
coefficient
Times of motor overload M = Iout/(In*K)
In is the rated current of the motor, Iout is the output current
of the inverter and K is the motor protection coefficient.
So, the bigger the value of K is, the smaller the value of M
is. When M =116%, the fault will be reported after 1 hour,
when M =200%, the fault will be reported after 1 minute,
when M>=400%, the fault will be reported instantly.
100.0%
○
