GD200A series VFD Product overview
-9-
Function
Specification
Peripheral
interface
Terminal analog input
resolution
20mV
Terminal switch input
resolution
2ms
Analog input
1 channels ( AI2) 0 (2)10V/0 (4)20mA and 1
channel (AI3) -1010V
Analog output
2 channels (AO1, AO2) 0 (2)10V /0 (4)20mA
Digital input
8 channels common input, max. frequency: 1kHz,
internal impedance: 3.3kΩ;
1 channel high speed input, max. frequency: 50kHz
Digital output
1 channel high speed pulse output, max. frequency:
50kHz;
1 channel Y terminal open collector pole output
Relay output
2 channels programmable relay output
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3A/AC250V,1A/DC30V
Others
Mountable method
Wall, flange and floor mountable
Temperature of the
running environment
-1050°C , derating is required if the temperature is
above 40°C . If the ambient temperature is above
40°C, derate 1% for every additionalC.
Ingress protection
IP20
Cooling
Air-cooling
Pollution level
Level 2
Braking unit
Built in 030G/037P and lower models.For other
models, it is an optional part.
EMC filter
380V series products can meet the requirements of
IEC61800-3 C3
External optional filter: meet the requirement of
IEC61800-3 C2
3.4 Nameplate
IP20
Model: GD200A-037G/045P-4
Power(Output): 37kW/45kW
Input: AC 3PH 380V(-15%)-440V(+10%) 80A/94A 47Hz-
63Hz
Output: AC 3PH 0V-Uinput 75A/92A 0Hz-400Hz
S/N: Made in China
Shenzhen INVT Electric Co.,Ltd
Figure 3-3 Nameplate
Note: This is the example of the nameplate for the standard products, and CE\TUV\IP20 will be
marked according to the actual situations.
