INVT GD200A-0R7G-4 User Manual

GD200A series VFD Peripheral options and parts
-163-
use a shielded cable.
The relay cable needs the cable type with braided metallic screen.
The keypad needs to connect with cables. It is recommended to use the screen cable on complex
electrical magnetic condition.
Note: Run analog and digital signals in separate cables.
Do not make any voltage tolerance or insulation resistance tests (for example hi-pot or megger) on
any part of the drive as testing can damage the drive. Every drive has been tested for insulation
between the main circuit and the chassis at the factory. Also, there are voltage-limiting circuits inside
the drive which cut down the testing voltage automatically.
Check the insulation of the input power cable according to local regulations before connecting to the
drive.
Note: Check the insulation of the input power cables according to local regulations before
connecting the cables.
VFD model
Recommended cable size(mm
2
)
Screw
R,S,T
U,V,W
PE
P1 (+)
PB (+) (-)
Terminal
screw
size
Tightening
torque (Nm)
GD200A-0R7G-4
1.0
1.0
1.0
1.0
M4
1.2–1.5
GD200A-1R5G-4
1.0
1.0
1.0
1.0
M4
1.2–1.5
GD200A-2R2G-4
1.0
1.0
1.0
1.0
M4
1.2–1.5
GD200A-004G/5R5P-4
1.5/1.5
1.5/1.5
1.5/1.5
1.5/1.5
M4
1.2–1.5
GD200A-5R5G/7R5P-4
1.5/2.5
1.5/2.5
1.5/2.5
1.5/2.5
M5
2–2.5
GD200A-7R5G/011P-4
2.5/4
2.5/4
2.5/4
2.5/4
M5
2–2.5
GD200A-011G/015P-4
4/6
4/6
4/6
4/6
M5
2–2.5
GD200A-015G/018P-4
6/10
6/10
6/10
6/10
M5
2–2.5
GD200A-018G/022P-4
10/10
10/10
10/10
10/10
M6
4–6
GD200A-022G/030P-4
10/16
10/16
10/16
10/16
M6
4–6
GD200A-030G/037P-4
16/25
16/25
16/25
16/25
M8
9–11
GD200A-037G/045P-4
25/25
16/16
25/25
25/25
M8
9–11
GD200A-045G/055P-4
25/35
16/16
25/35
25/35
M8
9–11
GD200A-055G/075P-4
35/50
16/25
35/50
35/50
M10
18–23
GD200A-075G/090P-4
50/70
25/35
50/70
50/70
M10
18–23
GD200A-090G/110P-4
70/95
35/50
70/95
70/95
M10
18–23
GD200A-110G/132P-4
95/95
50/50
95/95
95/95
M12
31–40
GD200A-132G/160P-4
95/150
50/70
95/150
95/150
M12
31–40
GD200A-160G/185P -4
150/185
70/95
150/185
150/185
M12
31–40
GD200A-185G/200P-4
185/
185
95/95
185/
185
185/
185
M12
31–40
