INVT GD200A-0R7G-4 User Manual

GD200A series VFD Function parameters
-57-
Function
code
Name
Description
Default
value
Modify
P05.06
S6 terminal
function
selection
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time option terminal 1
22: ACC/DEC time option terminal 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse Pause(stop at the current frequency)
27: Traverse reset(return to the center frequency)
28: Counter reset
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Length reset
33: Cancel the frequency change setting
temporarily
34: DC brake
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-exciting command
40: Clear the power consumption
41: Keep the power consumption
61: PID pole switching
When the terminal acts as acceleration/
deceleration time selection function, it is required
to select four groups of acceleration/deceleration
time via state combination of these two terminal
(while terminal 1 choose 21, terminal 2 choose 22)
Terminal1
(21)
Terminal2
(22)
ACC/DEC time
selection
Parameters
OFF
OFF
ACC/DEC time 1
P00.11/P00.12
ON
OFF
ACC/DEC time 2
P08.00/P08.01
OFF
ON
ACC/DEC time 3
P08.02/P08.03
ON
ON
ACC/DEC time 4
P08.04/P08.05
0
◎
P05.07
S7 terminal
function
selection
0
◎
P05.08
S8 terminal
function
selection
0
◎
P05.09
HDI terminal
function
selection
0
◎
P05.10
Polarity
selection of the
input terminals
The function code is used to set the polarity of the
input terminals.
Set the bit to 0, the input terminal is anode.
0x000
○
