Goodrive300 Series VFD Function parameters
122
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P17.09
Output torque
Display the current output torque of the VFD.
Range: -250.0–250.0%
0.0%
●
P17.10
Evaluated
motor
frequency
Evaluate the motor rotor frequency on close loop
vector.
Range: 0.00– P00.03
0.00Hz
●
P17.11
DC bus
voltage
Display current DC bus voltage of the VFD.
Range: 0.0–2000.0V
0.0V
●
P17.12
Digital input
terminals state
Display current Switch input terminals state of the
VFD.
BIT8
BIT7
BIT6
BIT5
HDI
S8
S7
S6
BIT4
BIT3
BIT2
BIT1
BIT0
S5
S4
S3
S2
S1
Range: 0000–01FF
0
●
P17.13
Digital output
terminals state
Display current Switch output terminals state of
the VFD.
BIT3
BIT2
BIT1
BIT0
RO2
RO1
HDO
Y
Range: 0000–000F
0
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the
VFD.
Range: 0.00Hz–P00.03
0.00Hz
●
P17.15
Torque
reference
Display the torque given, the percentage to the
current rated torque of the motor.
Setting range: -300.0%–300.0% (the rated
current of the motor)
0.0%
●
P17.16
Linear speed
Display the current linear speed of the VFD.
Range: 0–65535
0
●
P17.17
Length
Display the current length of the VFD.
Range: 0–65535
0
●
P17.18
Count value
Display the current counting number of the VFD.
Range: 0–65535
0
●
P17.19
AI1 input
voltage
Display analog AI1 input signal.
Range: 0.00–10.00V
0.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal.
Range: 0.00–10.00V
0.00V
●
