Goodrive300 Series VFD Function parameters
103
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
speed 5
terminals 1–4 (select the setting by S terminals,
the corresponding function codes are
P05.01–P05.09), corresponding to the speed 1 to
speed 15.
Output frequency
t
t
t
t
t
S1
S2
S3
S4
When terminal 1, terminal 2, terminal 3, terminal
4=OFF, the frequency input manner is selected
via code P00.06 or P00.07. When terminal 1,
terminal 2, terminal 3, terminal 4 aren’t off, it runs
at multi-step which takes precedence of keypad,
analog value, high-speed pulse, PLC,
communication frequency input.
The relationship between terminal 1, terminal 2,
terminal 3, terminal 4 and multi-step speed is as
following:
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Step
0
1
2
3
4
5
6
7
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
ON
ON
ON
ON
ON
ON
ON
ON
Step
8
9
10
11
12
13
14
15
P10.13
Running time
of step 5
0.0s
○
P10.14
Multi-step
speed 6
0.0%
○
P10.15
Running time
of step 6
0.0s
○
P10.16
Multi-step
speed 7
0.0%
○
P10.17
Running time
of step 7
0.0s
○
P10.18
Multi-step
speed 8
0.0%
○
P10.19
Running time
of step 8
0.0s
○
P10.20
Multi-step
speed 9
0.0%
○
P10.21
Running time
of step 9
0.0s
○
P10.22
Multi-step
speed 10
0.0%
○
P10.23
Running time
of step 10
0.0s
○
P10.24
Multi-step
speed 11
0.0%
○
P10.25
Running time
of step 11
0.0s
○
P10.26
Multi-step
speed 12
0.0%
○
P10.27
Running time
of step 12
0.0s
○
P10.28
Multi-step
speed 13
0.0%
○
P10.29
Running time
of step 13
0.0s
○
P10.30
Multi-step
speed 14
0.0%
○
