INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
36
Function
code
Name
Detailed illustration of parameters
Default
Modify
20: External fault valid
21: Reserved
22: Running time arrival
23: Modbus communication virtual
terminals output
24–26: Reserved
27: Weak light
28–29: Reserved
30: Shift to PV mode (If the system works
in PV mode, relay output is high.)
P06.05
Polarity selection
of output
terminals
The function code is used to set the pole
of the output terminal.
When the current bit is set to 0, output
terminal is positive.
When the current bit is set to 1, output
terminal is negative.
BIT1
BIT0
RO2
RO1
Setting range: 0–F
0
○
P06.10
Switch on delay of
RO1
0.000–50.000s
10.000s
○
P06.11
Switch off delay of
RO1
0.000–50.000s
10.000s
○
P06.12
Switch on delay of
RO2
0.000–50.000s
0.000s
○
P06.13
Switch off delay of
RO2
0.000–50.000s
0.000s
○
