Goodrive100-PV Series Solar Pumping VFD Function parameters
35
Function
code
Name
Detailed illustration of parameters
Default
Modify
46: PV voltage digital input when no boost
module is applied (in auto switching
mode)
47–63: Reserved
P05.10
Polarity selection
of the input
terminals
0x000–0x10F
BIT8
BIT3
BIT2
BIT1
BIT0
HDI
S4
S3
S2
S1
0x000
◎
P06 Group Output terminals
P06.03
Relay RO1 output
selection
0: Invalid
1: In operation
2: Forward rotation operation
3: Reverse rotation operation
4: Jogging operation
5: VFD fault
6: Frequency degree test FDT1
7: Frequency degree test FDT2
8: Frequency arrival
9: Zero speed running
10: Upper limit frequency arrival
11: Lower limit frequency arrival
12: Ready for operation
13: Pre-magnetizing
14: Overload alarm
15: Underload alarm
16: Completion of simple PLC stage
17: Completion of simple PLC cycle
18: Setting count value arrival
19: Defined count value arrival
30
○
P06.04
Relay RO2 output
selection
5
○
