INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
45
Function
code
Name
Detailed illustration of parameters
Default
Modify
P15.10
PI switching point
0.0–6553.5Vdc
If the absolute value of bus voltage
minus the reference value is bigger than
P15.10, it will switch to P15.08 and
P15.09; otherwise it is P15.06 and
P15.07.
20.0V
◎
P15.11
Water level
control
0: Digital input of the water-level control
1: AI1(the water-level signal is input
through AI1, not supported currently)
2: AI2 (the water-level signal is input
through AI2, not supported currently)
3: AI3 (the water-level signal is input
through AI3, not supported currently)
If the function code is 0, the water-level
signal is controlled by the digital input.
See 43 and 44 functions of S terminals
in group P05 for detailed information. If
the full-water signal is valid, the system
will report the alarm (A-tF) and sleep
after the time of P15.14. During the
alarm, the full-water signal is invalid and
the system will clear the alarm after the
time of P15.15. If the empty-water signal
is valid, the system will report the alarm
(A-tL) and sleep after the time of
P15.16. During the alarm, the empty
-water signal is invalid and the system
will clear the alarm after the time of
0
◎
