INVT Goodrive100-PV Series User Manual

Goodrive100-PV Series Solar Pumping VFD Function parameters
52
Function
code
Name
Detailed illustration of parameters
Default
Modify
P15.28
Adjustment of
initial reference
voltage
0.0–200.0V
MPPT begins to change from the
reference voltage
Initial reference voltage =PV
voltage-P15.28
5.0V
○
P15.29
Adjustment of
upper and lower
limit time of Vmppt
0.0–10.0s
When P15.29 is set to 0.0, the
automatic adjustment is invalid.
If it is not 0.0, the upper and lower limits
of Vmppt will be adjusted automatically
at the inveral set by P15.29. The
medium value is the current PV voltage
and the limit is P15.30:
Maximum/Minimum reference
voltage=Current PV voltge±P15.30 and
it will update to P15.26 and P15.27 at
the same time.
1.0s
○
P15.30
Adjustment of
upper and lower
limits of Vmppt
5.0–100.0V
Adjustment of the upper and lower limits
30.0V
○
P15.31
Max. value of
Vmppt
P15.27–6553.5V
During the maximum power tracking,
the upper limit of the solar cell panel
reference voltage will not exceed the
value set by P15.31. The factory value
depends on the model. By default, the
value for the -4 models is 750V and the
value for other models is 400V.
400.0V
○
