Goodrive300-01A series VFD for air compressor Function code description
-59-
Function
code
Name
Parameter description
Default
value
Modify
sequence state
and input phase loss hardware protection,
corresponding fault will be reported when
negative sequence and any phase loss
occurs; otherwise, fault will not be reported.
0: Positive sequence
1: Negative sequence
2: R phase loss
3: S phase loss
4: T phase loss
P19.23
State of phase
sequence detection flat
cable
0: Normal, indicating the flat cable is plugged
in properly
1: Abnormal, indicating the flat cable is not
plugged in
0
●
P20.00
Encoder type selection
0–1: Reserved
2: Resolver-type encoder
3: Reserved
2
◎
P20.01
Number of PPR (pulse
per revolution) of
encoder
0–60000 (number of resolver pole pairs*1024)
1024
◎
P20.02
Encoder direction
0: Forward 1: Reverse
0
◎
P20.03
Encoder offline
detection time
0.0–10.0s
0.8s
○
P20.04
Encoder reverse
detection time
0.0–100.0s
0.8s
○
P20.05
Encoder detection filter
times
Ones: Low speed filter times
Tens: High speed filter times
0x33
○
P20.06
Speed ratio between
motor and encoder
0–65.535
1.000
○
P20.07
Control parameters of
synchronous motor
Bit0: Z pulse calibration enable
Bit1: Encoder angle calibration enable
Bit2: SVC speed measurement enable
Bit3: Resolver speed measurement mode
selection
Setting range: 0x0–0xF
0x3
○
P20.08
Z pulse offline
detection enable
0–1
0
○
P20.09
Initial angle of Z pulse
0–359.99
0.00
○
P20.10
Initial angle of
magnetic pole
0–359.99
0.00
○
