Goodrive300-01A series VFD for air compressor Appendix A
-76-
Power
W1
W2
W3
H1
H2
D1
D2
Diameter of
mounting hole
7.5kW
170
151
320
303.5
196.5
113
6
11kW22kW
200
185
340.5
328.5
184.5
104.5
6
30kW37kW
250
230
400
380
202
123.5
6
45kW55kW
282
160
226.0
560
542
238
138
9
75KW
370
220
590
572
250
---
9
90110KW
338
200
554
535
337
9.5
132kW200kW
500
180
870
850
360
11
H1
H2
W1
W2
D2
Ø
D1
Figure A-6 Wall installation diagram of 7.5kW15kW single VFD integrated machine
Table A-2 Wall installation dimension of 7.5kW15kW single-VFD integrated machine (unit: mm)
Power
W1
W2
H1
H2
D1
D2
Diameter of
mounting hole
7.5kW15kW
200
185
340.5
328.5
184.5
104.5
6
A.4 Flange installation dimension
Figure A-7 7.5kW55kW flange installation diagram
