Goodrive300-01A series VFD for air compressor Fault information and troubleshooting
-71-
P19.14
State type
Possible cause
Solution
BIT0=1
Part 1 needs
maintenance
The running time of part 1
exceeds the time set by
P19.00.
Carry out maintenance after stop
BIT1=1
Part 2 needs
maintenance
The running time of part 2
exceeds the time set by
P19.01.
Carry out maintenance after stop
BIT2=1
Part 3 needs
maintenance
The running time of part 3
exceeds the time set by
P19.02.
Carry out maintenance after stop
BIT3=1
Part 4 needs
maintenance
The running time of part 4
exceeds the time set by
P19.03.
Carry out maintenance after stop
BIT4=1
Part 5 needs
maintenance
The running time of part 5
exceeds the time set by
P19.04.
Carry out maintenance after stop
BIT5=1
Auxiliary pressure
signal fault
The actual voltage detected
by P2 is less than 1V.
• Pressure detection sensor is
abnormal.
• Pressure detection input P2
signal wire is disconnected.
BIT6=1
Auxiliary temperature
signal fault
PT100 sensor is
disconnected.
• Check whether the wiring of
PT100 is normal.
• Temperature detection sensor
is abnormal.
• Temperature detection input
circuit is abnormal.
BIT7=1
Auxiliary pressure
pre-alarm
The actual voltage detected
by P2 is larger than the
pre-alarm pressure set by
P18.17
• Pressure detection sensor is
abnormal.
• The pressure is set to a too
large value.
• Adjust pressure PID regulator.
BIT8=1
Auxiliary temperature
pre-alarm
The actual temperature
detected by PT2 is larger
than the pre-alarm
temperature set by P18.19
• Temperature detection sensor
is abnormal.
• Temperature detection input
circuit is abnormal, if not
calibrated.
• The starting temperature of
the fan is set to a too high
value.
• The temperature of the fan is
set to a too high value.
• Fan power is too small to
