INVT Goodrive300-01A Series User Manual

Goodrive300-01A series VFD for air compressor Appendix D
-86-
Function
description
Address
definition
Data meaning
R/W
attribute
2008H
Upper limit torque of brake torque (0–3000,
1000 corresponds to 100.0% rated motor
current)
W/R
2009H
Special control command word:
Bit0–1: =00: Motor 1 =01: Motor 2
=10: Motor 3 =11: Motor 4
Bit2: =1 Torque control =0: Speed control
Bit3: =1 Power consumption cleared to zero
=0: Power consumption not cleared to zero
Bit4: =1 Pre-excitation =0: Pre-excitation
forbidden
Bit5: =1 DC brake =0: DC brake forbidden
W/R
200AH
Virtual input terminal command, range:
0x000–0x1FF
W/R
200BH
Virtual output terminal command, range:
0x00–0x0F
W/R
200CH
The set voltage value (used for V/F
separation)
(0–1000, 1000 corresponds to 100.0% rated
motor voltage)
W/R
200DH
The set value 1 of AO output (-1000–1000,
1000 corresponds to 100.0%)
W/R
200EH
The set value 2 of AO output (-1000–1000,
1000 corresponds to 100.0%)
W/R
200FH
BIT0: =1 running time of part 1 cleared to
zero; =0: invalid
BIT1: =1 running time of part 2 cleared to zero
=0: invalid
BIT2: =1 running time of part 3 cleared to zero
=0: invalid
BIT3: =1 running time of part 4 cleared to zero
=0: invalid
BIT4: =1 running time of part 5 cleared to zero
=0: invalid
BIT5: =1 device running time cleared to zero
=0: invalid
BIT6: =1 solenoid valve loading =0: solenoid
valve unloading
W/R
2010H
The set maintenance time of part 1;
Range: 0–65535
W
