INVT SPC7K5TR40 - P04 Group Space Voltage Vector Control

SPC Series Solar Pump Inverter Function parameter list
-25-
Function
code
Name
Description
Default
Modify
P02.10
No-load current
of AM
0.1–6553.5A
performance.
Note: Do not modify
these parameters
unless it is necessary.
Model
depended
○
P02.15
Rated power of
SM
0.1–3000.0kW
0.1–3000.0
Model
depended
◎
P02.16
Rated
frequency of
SM
0.01Hz–P00.03
(Max. output
frequency)
0.01–P00.03
110.00Hz
◎
P02.17
Number of pole
pairs of SM
1–128
1–128
2
◎
P02.18
Rated voltage
of SM
0–1200V
0–1200
Model
depended
◎
P02.19
Rated current
of SM
0.8–6000.0A
0.8–6000.0
Model
depended
◎
P02.20
Stator
resistance of
SM
0.001–65.535Ω
0.001–65.535
Model
depended
○
P02.21
Direct-axis
inductance of
SM
0.01–655.35Mh
0.01–655.35
Model
depended
○
P02.22
Quadrature-
axis inductance
of SM
0.01–655.35Mh
0.01–655.35
Model
depended
○
P02.23
Counter-emf of
SM
0–10000
0–10000
300
○
P04 group Space voltage vector control
Function
code
Name
Description
Default
Modify
P04.00
V/F curve
setting
This group of function code defines the
V/F curve of motor 1 to meet the needs of
different loads.
0: Straight-line V/F curve, applicable to
constant torque loads
1: Reserved
0
◎
