Step 5
Connect the Cascade Cable between the 1st level KVM and 2nd level KVM. Connect the green connector
to 1 of the 1st level KVM switch’s CPU port. Then, connect the yellow connector to the console port of the
2nd level KVM switch.
1st Level
2nd Level
