Connect a computer power supply cable.
M N0TE: If all available power supply cables have micro connectors,
you will need a power cable converter. If the computer does not
have a spare power supply cable, you will need a power Y-cable. M
Zip ATAPI Drive
Power Supply Cable from Computer
CAUTION Make sure the power supply cable is securely connected to
the Zip drive. M
Secure drive in drive bay (mounting screws are in
the 3.5” Universal Installation kit)
.
Align the front of the Zip drive with other drives installed in the computer.
If there is not clear access to the drive bay mounting holes, refer to your
computer manual for additional instructions. Note that if the drive is held
in place securely by rails, you will not need to use the mounting screws.
Drive Bay Mounting
Screws (6-32)
CAUTION Mounting screws must not extend into the Zip ATAPI
drive farther than 4.0 mm (about 0.16 inch). Mounting screws that
are too long could damage the drive. M
12
7
Installation Guide
11
