ION 30ACi+ User Manual

OPERATION MANUAL
Dated: 02/10/2015
Document Name: 30-35ACi+&Deluxe_OM
Page 6 of 12
30ACi+, 30ACi Deluxe,
35ACi+ and 35ACi Deluxe
Battery Backup System
Register your product at www.sumpro.com
BacK panel
The inverter has two battery leads coming out from the back of the inverter, with a grey Anderson connector on
the end, a MCB (main circuit breaker), pump output socket (120 volt) and a power cord to connect with AC power
(120 volt). The Anderson connector on the inverter leads gets connected to the Anderson connector on the Pig Tail
coming from the battery.
front panel
DC MODEAC MODE
Output VoltageOutput Voltage
Amount of LoadAmount of Load
Battery Display
Battery Display
Charge in
Batteries
Charge in
Batteries
Frequency/
Load Amps
Input
Voltage/
Load Amps
Pump Outlet
Main Circuit Breaker
Quick Connect
Battery Leads
Pump Outlet
Date of Manufacture Label
120 Volt
Power Cord
Main Circuit Breaker
Quick Connect
Battery Leads
Anderson
Connector
Anderson
Connector
30ACi+/30ACi Deluxe 35ACi+/35ACi Deluxe
