Appendix A. Technical Specifications
Model
HAE69 and HAE69EC
Mount
Strain Wave Altazimuth/Equatorial Mount
RA/DEC gear system
StrainWave
RA reduction ratio
RA 800:1, DEC 800:1
Payload w/o CW*
69 lbs (31kg)
Mount weight
19 lbs (8.6 kg) with dovetail saddle
Payload/Mount weight
3.6
Payload with CW
79 lbs (36 kg)
Structure Material
All metal, CNC machined, Anodized
High precision encoder
Yes (RA, HAE69EC only)
PEC
Realtime PEC (RPEC) (HAE69EC only)
Period
270 second
Drive motor
Stepper motor
Latitude adjustment range
0º ~ 90º
Azimuth adjustment range
± 8º
Polar Scope
External iPolar
TM
electronic polar scope (optional)
Level indicator
Level bubble
Hand Controller
Go2Nova
®
8409 with 212,000 objects database
Tracking
Automatic
Speed
1×,2×,8×,16×,64×,128×,256×,512×,MAX(4.5°/sec)
Power consumption
0.6A(Tracking), 1.6A(GOTO)
AC/DC adapter
AC100V~240V input, DC12V-5A output (included,
indoor use only)
Power off brake
Electronic friction brake
Power-down memory
Yes
Wi-Fi
Built-in (via HC)
Communication port
Yes (USB and Wi-Fi)
Autoguide port
Yes (ST-4 compatible)
Firmware upgrade
Yes
Computer control
Yes
Dovetail saddle
Vixen/Losmandy dual saddle
Base diameter
152mm
Counterweight shaft
SS Φ20mmX200mm, 3/8-16 thread (optional)
Counterweight
10 lb (4.5kg) (optional)
Tripod
Optional
Autoguider
Optional external iGuider
Operation temperature
-20ºC ~ 40ºC (hand controller -10ºC ~ 40ºC)
Warranty
Two year limited
* Payload calculated with payload center of gravity to the RA rotation axis is 200mm.
