#9101 and #9102 Ranger MUTT
®
PARTS
Use the reference numbers provided when ordering products and parts above.
Toll Free: 888-786-7899
(Line art for both #9101 and #9102 units. See 7-Way Socket descriptions for variations between units.)
Fig. 1 - Parts Diagram
Rubber Gasket
12V Cigarette Socket
Lid Lock
Switch Plate
Control Knob
Enclosure
Battery Compartment
Rotary Switch
Padlock Hole
Power LED
7-Way Flat Socket (#9101)
7-Way Round Socket (#9102)
500mA Battery Charger
#CHR0001
(Included with #9101 & #9102)
3-Way Trailer Adapter
#8000
(Included with #9101 only)
IMPORTANT SAFETY INSTRUCTIONS
IT IS IMPORTANT TO READ, UNDERSTAND AND FOLLOW ALL SAFETY MESSAGES
AND INSTRUCTIONS PRINTED IN THIS MANUAL AND ON THE EQUIPMENT BE-
FORE OPERATING. IF SAFETY INFORMATION IS NOT HEEDED, SERIOUS INJURY
OR DEATH TO THE OPERATOR OR BYSTANDERS MAY OCCUR.
DANGER: Indicates a hazardous situation, if not avoided, will result in death or serious
injury. The possible hazards are shown in the adjoining symbols or explained in the text.
WARNING: Indicates a hazardous situation, if not avoided, could result in death or serious
injury. The possible hazards are shown in the adjoining symbols or explained in the text.
CAUTION: Indicates a hazardous situation, if not avoided, may result in minor or major
injury. The possible hazards are shown in the adjoining symbols or explained in the text.
Battery Leads
ACCESSORIES
