REPLACING THE CENTRE BRUSH
Caution: this operation must be carried out with the machine o and
the key removed.
This machine features a system for automatically adjusting the
pressure exerted and compensating for wear.
The need to replace the central brush is highlighted on the display
by the wording “BRUSH WORN OUT”
To replace the centre brush, proceed as follows:
Open up the door on the left hand side of the machine by loosening
the knob, as shown in the gure.
Unscrew and remove the knobs that x the brush housing cover
Remove the cover of the brush compartment.
Remove the worn brush.
Remove the adapter of the brush stem and t it onto the new brush.
Maintain the same inclination of the bristles.
(See the next gure).
Ret the adapter and mount the new brush. Make sure the adapter
is inserted into the hub.
