1 flashing red LED: battery voltage under 18 V (ACID batteries) or under 19 V (GEL
batteries), drive is shut down. Recharge the batteries.
1 red LED on steadily: battery voltage between 18 and 20.5 V (ACID batteries) or 19
and 21.5 V (GEL batteries), SUPER-MINIMUM battery charge. Recharge the batteries.
1 red LED + 1 yellow LED on steadily: battery voltage between 20.5 and 21.5 V (ACID
batteries) or 21.5 and 22.5 V (GEL batteries), MINIMUM battery charge.
1 red LED + 1 yellow LED + 1 green LED_1 on steadily: battery voltage between 21.5
and 24 V (ACID batteries) or 22.5 and 25 V (GEL batteries), MEDIUM battery charge.
1 red LED + 1 yellow LED + 1 green LED_1 + 1 green LED_2 on steadily: battery
voltage between 24 and 27.4 V (ACID batteries) or 25 and 28.4 V (GEL batteries),
MAXIMUM battery charge.
IMPORTANT
Each time you fill the solution tank, always empty the collection tank.
! DANGER
Use suitable personal protection devices.
• when the collection tank is full, the level indicator comes on (fig. A, ref. 11) and
after a few seconds the suction motor is turned off. You must stop working and
empty the tank.
Emptying the collection tank:
1 Stop the machine by releasing the pedal (fig. B, ref. 7)
2 Turn off all functions using the brush button (fig. A, ref. 8).
3 Take the machine to the disposal area.
4 Empty the collection tank through the hose (fig. B, ref. 10), then rinse the
tank with clean water.
Emptying the solution tank:
5 Proceed as described in points 1 to 3.
6 At the end of work, empty the solution tank by means of the tap (fig. E, ref.
4), then rinse the tank with clean water.
IMPORTANT
When washing the collection tank, never remove the suction filter (fig. G, ref. 1)
from its housing and never direct the jet of water against the filter itself.
You are then ready to wash and dry again.
Pushing and pulling the machine:
When the drive cannot be used, to push and pull the machine easily, you must
screw up the electromagnetic brake block handwheel.
After you have finished
moving the machine, unscrew the electromagnetic brake block handwheel.
IMPORTANT
If the handwheel is not unscrewed, the electromagnetic brake remains inactive.
Never turn the machine on with the electromagnetic brake block handwheel (fig.
F, ref. 1) screwed up (brake deactivated).
