IPSO TMB795C - Electrical Connection Locations

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Tumblers – 50 and 75
8
4-08-44
Electrical Connection Locations
TMB813N
TMB813N
GAS AND STEAM ELECTRIC
A
B
B
A
Models A B
Gas and Steam
9.5 in.
(241 mm)
63.5 in.
(1613 mm)
Electric
19 in.
(483 mm)
64 in.
(1626 mm)
NOTE: These figures are approximate dimensions only.
