MAN2030I (ECN5752) 8/99 5C D0539
MODELS
GAS STEAM ELECTRIC
DR30SLG DR30SLS DR30SLE
OWNER'S MANUAL
30 Lb. Laundry Dryer
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
IPSO-USA
3101 S. Haven Hwy. 77 Phone: (850)271-8486
Suite A
Panama City, FL 32405
- USA

Questions and Answers

  • A
    Alyssa LaneAug 1, 2025
    How to troubleshoot an IPSO DR30SLG when the motor won't start?
    • L
      Laura KimAug 1, 2025
      If the motor of your IPSO Dryer won't start, several factors could be at play. First, check the fuses on the circuit breakers and ensure the main control switch is turned on. For gas dryers, inspect the bonnet thermostat. Also, verify that the power source matches the electrical rating plate's specifications for voltage, phase, and frequency. Make sure the timer is properly set or the coin meter has vended correctly. Inspect wire connections in the electrical box at the dryer's rear. Ensure the loading door is fully closed and the door switch is correctly adjusted; if defective, replace it. Finally, check and replace the basket motor contactor if necessary, and reset or replace the safety thermostat on the gas bonnet if tripped or defective.
  • A
    Ann ArnoldAug 8, 2025
    Why is the motor tripping on thermal in my IPSO DR30SLG Dryer?
    • D
      Deanna GriffithAug 8, 2025
      If the motor in your IPSO Dryer is tripping on thermal, it could be due to several reasons. Begin by checking the voltage at the motor terminals, ensuring it's within +10% of the voltage specified on the motor rating plate. If the voltage is outside this range, contact your local power company for corrective measures. Also, consult with your power company to ensure the wiring is adequately sized for the load. Check all electrical connections and tighten any that are loose. Make sure there's adequate air by checking the installation sheet for recommended make-up air openings. Lastly, clean any lint that has accumulated on and around the motors.
  • K
    Kimberly PorterAug 15, 2025
    What to do if the motor runs but the basket won't revolve in my IPSO DR30SLG Dryer?
    • C
      Carrie JacobsAug 15, 2025
      If the motor of your IPSO Dryer runs but the basket won't revolve, the V-belt might be the issue. Check if the V-belt is broken and replace it if necessary. If the V-belt is loose, adjust the belt tension. Inspect the motor pulley to see if it's loose, and tighten the set screw if needed. Also, ensure that the basket is not overloaded; if it is, remove some of the load.
  • P
    patrick20Aug 25, 2025
    Why does my IPSO Dryer not stop at the end of the time period?
    • B
      blopezAug 25, 2025
      If your IPSO Dryer does not stop at the end of the time period, the timer may be defective and needs to be replaced.

Summary

IPSO DRYER WARRANTY

UNPACKING AND INITIAL SETUP

GENERAL SPECIFICATIONS FOR 30 LB. LAUNDRY DRYERS

30 LB. STEAM MODEL SPECIFICATIONS

30 LB. ELECTRIC MODEL SPECIFICATIONS

GROUNDING AND ELECTRICAL CONNECTION INSTRUCTIONS

GAS PIPING INSTALLATION REQUIREMENTS

GAS SERVICE INSTALLATION INSTRUCTIONS

GAS PIPE SIZE CHART

STEAM PIPING INSTALLATION INSTRUCTIONS

DRYER INSTALLATION WITH MULTIPLE EXHAUST

MULTIPLE EXHAUST DUCT INSTALLATION DETAILS

DRYER INSTALLATION WITH SEPARATE EXHAUST (PREFERRED)

SUGGESTED MINIMUM DRYER MAKE-UP AIR REQUIREMENTS

EXHAUST AND VENTING GUIDELINES

AIR FLOW, EXHAUST, AND MAKE-UP AIR REQUIREMENTS

Critical factors for proper dryer airflow, exhaust, and make-up air.

RULES FOR SAFE DRYER OPERATION

OPERATING INSTRUCTIONS FOR COIN METER MODELS

INSTRUCTIONS FOR SETTING TIME ON COMPUTERIZED COIN METER

SERVICE SAVERS AND TROUBLESHOOTING OVERVIEW

COMMON DRYER PROBLEMS AND SOLUTIONS

A guide to identifying and resolving frequent dryer operational issues.

TROUBLESHOOTING CHART-MOTOR AND DRIVE ISSUES

MOTOR WILL NOT START OR TRIPS THERMAL

Causes and remedies for motor starting failures or thermal overload.

TROUBLESHOOTING CHART-OPERATIONAL ANOMALIES

NOISY OPERATION AND LACK OF HEAT

Troubleshooting steps for dryer noise, vibration, and heating problems.

TROUBLESHOOTING CHART-HEATING AND BURNER ISSUES

DRYER TOO HOT, BURNER, AND GAS FLAME PROBLEMS

Diagnosing and resolving issues related to dryer temperature and burner performance.

TROUBLESHOOTING CHART-TEMPERATURE AND STEAM ISSUES

DIRECT SPARK IGNITION SYSTEM OPERATION

DIRECT SPARK IGNITION OPERATION FLOW CHART

GENERAL MAINTENANCE AND CARE PROCEDURES

DRYER SYSTEM INSPECTION AND CLEANING

BURNER AIR INLET SHUTTER ADJUSTMENT

BURNER AIRFLOW ADJUSTMENT AND TROUBLESHOOTING

30 LB. ELECTRIC BONNET “UR” MODEL-21 KW ELEMENT SPECIFICATIONS

POWER SUPPLY SPECIFICATIONS FOR ELECTRIC HEATING CIRCUITS
